**If you don't find the product you are looking for, please chat admin via WhatsApp to check the availability of the item
Equipped with an array of microphones for a wider field of view, the Fluke ii900 Sonic Industrial Imager enables maintenance teams to quickly and accurately locate air, gas and vacuum leaks in compressed air systems; even in a noisy environment. Designed especially for noisy production lines, SoundSight™ Technology is easy to learn and apply. The 7” LCD touch screen displays SoundMap™ on a visual image for quick identification of leak locations. A clear and intuitive interface allows technicians to isolate sound frequencies from leaks to filter out loud background noise. In a few hours, the team can inspect the entire plant - even in busy operations. For the first time, You can quickly and easily identify the air leak repairs needed to ensure efficient operation and reduce utility bills. Images can be saved and exported for reporting purposes. Never again take air leaks for granted.
Finally, there is an easy way to detect, locate and analyze partial discharges in one tool
Tired of spending too much time detecting partial discharges? Introducing the i910 Precision Acoustic Imger which is designed to find partial discharges, corona discharges, and gas and vacuum leaks. The ii910 acoustic imaging camera's breakthrough technology is a cost-efficient, safe, effective, and easy tool for teams inspecting and maintaining power distribution and industrial high-voltage equipment.
The invisible threat….now you can see it
Partial discharge is a serious issue that the team monitors on a daily basis. When scanning insulators, transformers, medium-voltage panels (switchgear), or high-voltage power lines, you need to be sure that you find the problem early and quickly. Undetected partial discharges can cause power outages, fires, explosions, or death from electric arcing. In addition to these hazards threatening the environment and human life, electric arcing can also cause costly losses. Equipment failure can cost millions of dollars per hour and research shows that a data center outage can cost as much as $8,851 per minute. Ultimately, the Department of Energy estimates that these outages cost the US economy $150 billion annually.
Important area to scan Partial Discharge
- Insulator
- Transformer
- High voltage power cable
- Medium voltage panels
- Lightning rod
- Busbar
- High voltage coil
- circuit breaker
- capacitor
Do it quickly and safely
The ii910 is the All-in-One tool you've been looking for for all your Leakage and Discharge problems. Everything you need is at your fingertips. Perform quick area or neighborhood scans and get all the pictures/video you need using simple one-button shooting and the large 7” touchscreen LCD. No need for additional tools or equipment. Without the need for complicated cables or secondary devices, you have full mobility and greater flexibility to switch between leak/partial discharge detection and repair of partial leak/discharge.
Fluke safety you can count on with performance you value
The Fluke ii910 Precision Acoustic Imager is the perfect tool for high-voltage electricians, electrical test technicians, and grid maintenance teams who constantly inspect and maintain power distribution and industrial high-voltage equipment. The ii910 provides a safe and fast way to detect and locate partial discharges to maintain high-voltage equipment and prevent catastrophic events. With SoundSight™ technology, the ii910 translates the sounds it hears into a visual representation so you can quickly find problem areas. The higher frequency capability of the ii910 enables early detection to facilitate earlier maintenance planning, which is why the ii910 has a frequency range of 2-100 kHz.
Find and repair them before the arc of fire appears
Partial discharges can cause a number of serious and costly problems ranging from severe equipment damage to lethal arcing. The only way to stop this from happening is to properly inspect and maintain the equipment. The ii910 Precision Acoustic Imager is built to make partial discharges faster and easier to find. Gone are the days of wearing headphones and listening to very faint or faint sounds on the tiny screen to find problems. Everything you need to remotely troubleshoot is right there in the ii910, without dangling and tangling cables or other accessories. Just pick it up, turn it on, and start troubleshooting.
The security you expect from a tough product you trust
Safety is key when working on high voltage equipment and at Fluke, safety is important, everything else is just a bonus. Due to a combination of special microphone positions and advanced algorithms the ii910 Acoustic Acoustic Imager can detect Partial Discharges and Corona Discharges from a distance of 120 meters. This means you can be farther away than necessary and still be effective and efficient in finding all of the problem areas. With no external cables or corner adjustment accessories, the ii910 ensures you don't get stuck in your gear while you work. In addition to acoustic imaging technology capable of capturing reflected sound, you don't even need a direct line of sight to spot a problem. This means you can find partial discharges without ever opening the cabinet.
Quickly find it easily without training
The ii910 is truly designed so that anyone can use it with little or no training. There's no need for certification anymore as you don't need one to operate this tool. Simply power on the ii910 with a single button, select a frequency range or let the tool do the work for you, and begin scanning immediately for partial discharges or leaks. Once you find a sound image, you can take a video or photo for later use after you've added text annotations. If you want to know more about a specific leak or partial discharge, turn to PDQ or LeakQ.
Tired of spending too much time detecting partial discharges? Introducing the i910 Precision Acoustic Imger which is designed to find partial discharges, corona discharges, and gas and vacuum leaks. The ii910 acoustic imaging camera's breakthrough technology is a cost-efficient, safe, effective, and easy tool for teams inspecting and maintaining power distribution and industrial high-voltage equipment.
The invisible threat….now you can see it
Partial discharge is a serious issue that the team monitors on a daily basis. When scanning insulators, transformers, medium-voltage panels (switchgear), or high-voltage power lines, you need to be sure that you find the problem early and quickly. Undetected partial discharges can cause power outages, fires, explosions, or death from electric arcing. In addition to these hazards threatening the environment and human life, electric arcing can also cause costly losses. Equipment failure can cost millions of dollars per hour and research shows that a data center outage can cost as much as $8,851 per minute. Ultimately, the Department of Energy estimates that these outages cost the US economy $150 billion annually.
Important area to scan Partial Discharge
- Insulator
- Transformer
- High voltage power cable
- Medium voltage panels
- Lightning rod
- Busbar
- High voltage coil
- circuit breaker
- capacitor
Do it quickly and safely
The ii910 is the All-in-One tool you've been looking for for all your Leakage and Discharge problems. Everything you need is at your fingertips. Perform quick area or neighborhood scans and get all the pictures/video you need using simple one-button shooting and the large 7” touchscreen LCD. No need for additional tools or equipment. Without the need for complicated cables or secondary devices, you have full mobility and greater flexibility to switch between leak/partial discharge detection and repair of partial leak/discharge.
Fluke safety you can count on with performance you value
The Fluke ii910 Precision Acoustic Imager is the perfect tool for high-voltage electricians, electrical test technicians, and grid maintenance teams who constantly inspect and maintain power distribution and industrial high-voltage equipment. The ii910 provides a safe and fast way to detect and locate partial discharges to maintain high-voltage equipment and prevent catastrophic events. With SoundSight™ technology, the ii910 translates the sounds it hears into a visual representation so you can quickly find problem areas. The higher frequency capability of the ii910 enables early detection to facilitate earlier maintenance planning, which is why the ii910 has a frequency range of 2-100 kHz.
Find and repair them before the arc of fire appears
Partial discharges can cause a number of serious and costly problems ranging from severe equipment damage to lethal arcing. The only way to stop this from happening is to properly inspect and maintain the equipment. The ii910 Precision Acoustic Imager is built to make partial discharges faster and easier to find. Gone are the days of wearing headphones and listening to very faint or faint sounds on the tiny screen to find problems. Everything you need to remotely troubleshoot is right there in the ii910, without dangling and tangling cables or other accessories. Just pick it up, turn it on, and start troubleshooting.
The security you expect from a tough product you trust
Safety is key when working on high voltage equipment and at Fluke, safety is important, everything else is just a bonus. Due to a combination of special microphone positions and advanced algorithms the ii910 Acoustic Acoustic Imager can detect Partial Discharges and Corona Discharges from a distance of 120 meters. This means you can be farther away than necessary and still be effective and efficient in finding all of the problem areas. With no external cables or corner adjustment accessories, the ii910 ensures you don't get stuck in your gear while you work. In addition to acoustic imaging technology capable of capturing reflected sound, you don't even need a direct line of sight to spot a problem. This means you can find partial discharges without ever opening the cabinet.
Quickly find it easily without training
The ii910 is truly designed so that anyone can use it with little or no training. There's no need for certification anymore as you don't need one to operate this tool. Simply power on the ii910 with a single button, select a frequency range or let the tool do the work for you, and begin scanning immediately for partial discharges or leaks. Once you find a sound image, you can take a video or photo for later use after you've added text annotations. If you want to know more about a specific leak or partial discharge, turn to PDQ or LeakQ.
Simplify complex motor drive troubleshooting with guided test setups and automatic drive measurement that provide reliable, repeatable test results.
The Fluke MDA 550 Motor-Drive Analyzer saves time and the hassle of setting up complex measurements, and simplifies the troubleshooting process. Simply select a step-by-step guided test and measurement will show you where to make voltage and current connections, while preset measurement profiles ensure you will get all the data you need for every critical motor drive part, from input to output, the DC bus, and the motor itself . Doing simple to complex measurements? MDA-550 can do it. What's more, making reports before (as-found) and after (as-left) repairs or adjustments becomes more practical. This is all thanks to its built-in report generator feature.
The MDA-550 is an ideal portable motor drive analysis testing tool. Not only that, this tool can also be used to safely detect and solve common problems in inverter-type motor drive systems.
- Measures main motor drive parameters , including voltage, current, DC bus voltage level and AC ripple, voltage and current unbalance and harmonics, voltage modulation, and motor shaft voltage discharge.
- Performs broader harmonic measurements to identify the impact of low and high order harmonics on your power system.
- Performs guided measurements of motor drive input, DC bus, drive output, motor input, and shaft measurements with step-by-step graphical diagrams of voltage and current connections.
- Uses simple measurement settings with preset measurement profiles to automatically trigger data collection based on the selected test procedure.
- Quickly and easily generate reports that are perfect for documenting problem solving and collaborative work with others.
- Measure additional electrical parameters with a complete 500 MHz oscilloscope, meter and logger capability for a wide range of electrical and electronic measurements in industrial systems
The Fluke MDA-550 Motor Drive Analyzer uses guided test measurements to make analysis even easier
Drive input
Quickly measure input voltage and current to see if values ??are within acceptable limits by comparing the rated voltage to the actual supply voltage. It then checks the input current to determine if the current is within its maximum rating and the conductor size is appropriate. You can also check if the harmonic distortion is within an acceptable level. There are two options for doing this: carefully examine the shape of the waveform or look at the harmonics spectrum screen which displays total harmonic distortion and individual harmonics.
Imbalance of voltage and current
Check the voltage unbalance at the input terminals so you can make sure the voltage unbalance is not too high (> 6-8%), and the phase rotation is correct. You can also check for current unbalance, as too large an imbalance can indicate a driving rectifier problem.
Wider harmonic measurement
Excess harmonics are not only a threat to your rotating machine, but also to other equipment connected to the mains power system. As well as being able to detect motor drive harmonics, the MDA-550 can also detect the potential impact of inverter switching electronics. The MDA-550 has three harmonic ranges, 1st to 51st harmonics, 1 to 9 kHz, and 9 kHz to 150 kHz providing the ability to detect harmonic pollution problems.
Bus DC
In motor drives, the conversion of AC to DC inside the drive is very important. The reason is that for the best drive performance it is necessary to have the right voltage and adequate smoothing with low ripple. High ripple voltages can be an indicator of a faulty capacitor or a faulty motor connected. The logging function can be used to dynamically check the performance of the DC bus in operating mode when load is applied.
Drive output
Check drive output focusing on voltage to frequency (V/F) ratio, and voltage modulation. If the V/F ratio is high, the motor may overheat. With a low V/F ratio, the connected motor may not be able to provide the torque required at the load to carry out the process for which it is intended.
Voltage modulation
Pulse Width Modulation signal measurements are used to check for high voltage peaks that can damage motor winding insulation. The rise time or steepness of the impulse is indicated by a dV/dt reading (value of change in voltage over time), this must be compared with the specified motor insulation. Metering can also be used to measure switching frequency. Its purpose is to detect whether there is a potential problem with the switching electronics, or with grounding, as the signal drifts up and down.
Input Motor
Ensuring the supply of voltage at the motor input terminal is important. However, choosing a connecting cable between the drive and the motor is no less important. Incorrect cable selection can cause damage to the drive and motor due to overvoltage peaks. Checking that the current at the terminals is within the motor's rating is critical because excess current can cause the motor to overheat, reducing the life of the stator insulation which can cause premature failure of the motor.
Motor shaft voltage
The voltage impulse in the variable speed drive is generated from the circuit between the motor stator and the rotor until a voltage appears on the rotor shaft. If the rotor shaft voltage exceeds the insulating capacity of the bearing grease, flashover currents (glow) may occur. As a result, pitting and fluting of the motor bearing rotation occurs, namely damage that causes the motor to fail prematurely. The MDA-550 is equipped with a carbon fiber brushed probe tip that makes it easy for you to detect destructive flashover currents. Meanwhile, the amplitude of the impulse and the number of events can be used as a consideration in taking preventive action. With the addition of these accessories and capabilities, you can spot potential faults without the need to buy expensive permanent solutions.
Step-by-step guided measurements ensure you have the data you need, when you need it
The MDA-550 is designed to help you quickly and easily test and troubleshoot common three-phase and single-phase inverter-type motor drive systems. Onscreen information and a step-by-step setup guide make it easy for you to configure the analyzer. Not only that, the information and guide will also provide the required drive measurements. That way, you can quickly make informed decisions regarding maintenance. From power input to attached motor, the MDA-550 provides measurement capabilities for the fastest motor drive solutions.
The Fluke MDA 550 Motor-Drive Analyzer saves time and the hassle of setting up complex measurements, and simplifies the troubleshooting process. Simply select a step-by-step guided test and measurement will show you where to make voltage and current connections, while preset measurement profiles ensure you will get all the data you need for every critical motor drive part, from input to output, the DC bus, and the motor itself . Doing simple to complex measurements? MDA-550 can do it. What's more, making reports before (as-found) and after (as-left) repairs or adjustments becomes more practical. This is all thanks to its built-in report generator feature.
The MDA-550 is an ideal portable motor drive analysis testing tool. Not only that, this tool can also be used to safely detect and solve common problems in inverter-type motor drive systems.
- Measures main motor drive parameters , including voltage, current, DC bus voltage level and AC ripple, voltage and current unbalance and harmonics, voltage modulation, and motor shaft voltage discharge.
- Performs broader harmonic measurements to identify the impact of low and high order harmonics on your power system.
- Performs guided measurements of motor drive input, DC bus, drive output, motor input, and shaft measurements with step-by-step graphical diagrams of voltage and current connections.
- Uses simple measurement settings with preset measurement profiles to automatically trigger data collection based on the selected test procedure.
- Quickly and easily generate reports that are perfect for documenting problem solving and collaborative work with others.
- Measure additional electrical parameters with a complete 500 MHz oscilloscope, meter and logger capability for a wide range of electrical and electronic measurements in industrial systems
The Fluke MDA-550 Motor Drive Analyzer uses guided test measurements to make analysis even easier
Drive input
Quickly measure input voltage and current to see if values ??are within acceptable limits by comparing the rated voltage to the actual supply voltage. It then checks the input current to determine if the current is within its maximum rating and the conductor size is appropriate. You can also check if the harmonic distortion is within an acceptable level. There are two options for doing this: carefully examine the shape of the waveform or look at the harmonics spectrum screen which displays total harmonic distortion and individual harmonics.
Imbalance of voltage and current
Check the voltage unbalance at the input terminals so you can make sure the voltage unbalance is not too high (> 6-8%), and the phase rotation is correct. You can also check for current unbalance, as too large an imbalance can indicate a driving rectifier problem.
Wider harmonic measurement
Excess harmonics are not only a threat to your rotating machine, but also to other equipment connected to the mains power system. As well as being able to detect motor drive harmonics, the MDA-550 can also detect the potential impact of inverter switching electronics. The MDA-550 has three harmonic ranges, 1st to 51st harmonics, 1 to 9 kHz, and 9 kHz to 150 kHz providing the ability to detect harmonic pollution problems.
Bus DC
In motor drives, the conversion of AC to DC inside the drive is very important. The reason is that for the best drive performance it is necessary to have the right voltage and adequate smoothing with low ripple. High ripple voltages can be an indicator of a faulty capacitor or a faulty motor connected. The logging function can be used to dynamically check the performance of the DC bus in operating mode when load is applied.
Drive output
Check drive output focusing on voltage to frequency (V/F) ratio, and voltage modulation. If the V/F ratio is high, the motor may overheat. With a low V/F ratio, the connected motor may not be able to provide the torque required at the load to carry out the process for which it is intended.
Voltage modulation
Pulse Width Modulation signal measurements are used to check for high voltage peaks that can damage motor winding insulation. The rise time or steepness of the impulse is indicated by a dV/dt reading (value of change in voltage over time), this must be compared with the specified motor insulation. Metering can also be used to measure switching frequency. Its purpose is to detect whether there is a potential problem with the switching electronics, or with grounding, as the signal drifts up and down.
Input Motor
Ensuring the supply of voltage at the motor input terminal is important. However, choosing a connecting cable between the drive and the motor is no less important. Incorrect cable selection can cause damage to the drive and motor due to overvoltage peaks. Checking that the current at the terminals is within the motor's rating is critical because excess current can cause the motor to overheat, reducing the life of the stator insulation which can cause premature failure of the motor.
Motor shaft voltage
The voltage impulse in the variable speed drive is generated from the circuit between the motor stator and the rotor until a voltage appears on the rotor shaft. If the rotor shaft voltage exceeds the insulating capacity of the bearing grease, flashover currents (glow) may occur. As a result, pitting and fluting of the motor bearing rotation occurs, namely damage that causes the motor to fail prematurely. The MDA-550 is equipped with a carbon fiber brushed probe tip that makes it easy for you to detect destructive flashover currents. Meanwhile, the amplitude of the impulse and the number of events can be used as a consideration in taking preventive action. With the addition of these accessories and capabilities, you can spot potential faults without the need to buy expensive permanent solutions.
Step-by-step guided measurements ensure you have the data you need, when you need it
The MDA-550 is designed to help you quickly and easily test and troubleshoot common three-phase and single-phase inverter-type motor drive systems. Onscreen information and a step-by-step setup guide make it easy for you to configure the analyzer. Not only that, the information and guide will also provide the required drive measurements. That way, you can quickly make informed decisions regarding maintenance. From power input to attached motor, the MDA-550 provides measurement capabilities for the fastest motor drive solutions.
Automatic measurement. Higher flexibility. Better power quality troubleshooting.
The Fluke 1770 Series Three-Phase Power Quality Analyzer takes the hassle out of power quality logging, troubleshooting, and analysis. Designed to be a faster and easier way to conduct power quality studies, the 1770 Series offers automatic measurements, a simple user interface and setup, best-in-class specifications, and a simpler reporting platform. The instrument can also be powered directly from the measuring circuit, eliminating the need to find an electrical outlet or use long extension cords
With the 1770 Series, you'll never miss critical power quality events—from fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, and voltage, current, and power measurements that let you understand your electrical system.
Automatic measurement recording
Whether you're doing a quick system check or a detailed power quality study, consistent data is key. The Fluke 1770 Series offers a unique automated measurement taking system that helps ensure you collect the right data every time, while giving you the flexibility to select and adjust certain parameters as needed. Over 500 power quality parameters are recorded by default and guided setup makes it easy to select the right parameters for the system you are working with. Logged data is instantly viewable, downloadable, and shareable with the Fluke Energy Analyze Plus software so you don't have to wait to finish your session before reviewing results or analyzing data
Best measurement confidence
The Fluke 1770 Series is a 2-in-1 device that combines the troubleshooting functionality of a power quality meter with the powerful analysis and logging capabilities of a standalone power quality analyzer—in one easy-to-use handheld device.
The 'Power Quality Meter' function gives you direct access to live data on the screen while in the field, so you can quickly identify potential problems when troubleshooting. The detailed 'Power Quality Logging and Analysis' function takes the hassle out of performing a power quality assessment by guiding you through the setup process to ensure you are capturing the right data every time. Combine these various measurement modes with the unique metering connection auto-correction function, and you can rest assured you won't have to go back for a second measurement—even if you weren't sure what to look for when you started.
Powerful analysis software with easy-to-generate reports
The Fluke 1770 Series Power Quality Analyzers are equipped with the powerful Fluke Energy Analyze Plus software. This software is designed to take the hassle out of other multi-purpose application software. Energy Analyze Plus helps you easily evaluate power quality data, without the need for lengthy training.
Energy Analyze Plus makes it easy to download, analyze, track and report on power quality and energy data. Quickly compare results to historical values, benchmark against industry norms, compare measured data to local conditions, and create a more complete picture of what's happening across your facility, even while data is still being collected. Energy Analyze Plus offers integrated support for the Fluke 1730, 1740, and 1770 Series of Energy Loggers and Power Quality Analyzers.
“In-workshop” and “in-the-field” setup and download via PC application software
- Simple data download using a USB memory stick, WiFi, LTE, Ethernet cable or USB cable
- Analyze every detail of energy consumption and power quality health status with automatic reports
- One-touch reporting creates standardized reports that comply with standards such as EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual or CSV compatible formats for use with third-party software
- Advanced analysis allows users to select recorded parameters and create highly customized measurement views for advanced data correlation
Power Quality
High speed voltage transient recording
Transients negatively affect a healthy system every day and their potential to damage your equipment should not be underestimated. Whether your system experiences impulsive or oscillating transients, the results can be catastrophic and result in problems ranging from insulation failure to total equipment failure. The Fluke 1775 and Fluke 1777 feature advanced transient recording technology to help you clearly identify high-voltage transient conditions, so you have the data you need to stop them. The Fluke 1775 Power Quality Analyzer has 1 MHz sampling capability to record fast transients, while the Fluke 1777 Power Quality Analyzer has 20 MHz sampling capability to record the fastest transients in high detail.
From conventional industrial systems to renewable energy systems to electric vehicles, we have the tools
The Fluke 1770 Series is designed to be safe and easy to use in any measurement environment. The 1770 Series lets you record a variable range of full power quality as well as high speed waveforms, high speed transients and higher frequency harmonics. Everything can be seen directly on the large high-resolution screen. With best-in-class CAT IV 600 V / CAT III 1000 V overvoltage ratings, this analyzer can be used in mains or downstream input receivers, measuring AC and DC inputs, as well as measuring harmonics up to 30 kHz. With the 1770 Series, you can rest assured that you will capture the data you need to make better maintenance decisions, whatever the task.
In accordance with international standards
The Fluke 1770 Series offers the best-in-class accuracy you expect from a Fluke Power Quality Analyzer in a package that meets IEC 61000-4-30 Class A next edition 3. In addition, the 1770 Series has been designed to meet the requirements of the upcoming Class A edition, to comply with EN 50160 and IEEE 519, so you are well prepared to address your future measurement needs.
Work where, when, and how you want
The situation on the ground is different every day. You need a power quality analyzer that you can always carry with you and work the way you need it. With a wide range of accessories and built-in features, the Fluke 1770 Series makes it easy to get the job done. The slim ergonomic design and integrated wrist strap make it easy to hold and the included hanging kit makes it easy to store your analyzer in the cabinet. The integrated internal power supply allows the unit to be powered directly from a rated circuit, while a 90-minute battery helps ensure you can still access and review data even when not connected to a live system.
Transfer data quickly and easily to your PC using USB C, USB A, Ethernet, Wi-Fi, or mobile network support options, depending on your needs. With the built-in GPS module and optional dual isolation antenna extension cable to amplify indoor GPS signals, you can easily synchronize your data with the time for more accurate troubleshooting and analysis.
Calculate current harmonic limits
When downloading data from the Fluke 1770 Series Power Quality Analyzer, the included Energy Analyze Plus software package can compare rated voltage and current harmonics statistical data against various standards, such as EN 50160 or IEEE 519. This is to determine if the data exceeds compliance limits. . With this advanced predictive maintenance feature, current harmonics can be spotted before distortions in voltage appear, so you can prevent unexpected failures or inappropriate situations and increase system uptime. With inverter-based loads and power generation increasing, keeping current harmonics in line is becoming increasingly important to ensure reliable power quality and avoid system downtime.
The Fluke 1770 Series Three-Phase Power Quality Analyzer takes the hassle out of power quality logging, troubleshooting, and analysis. Designed to be a faster and easier way to conduct power quality studies, the 1770 Series offers automatic measurements, a simple user interface and setup, best-in-class specifications, and a simpler reporting platform. The instrument can also be powered directly from the measuring circuit, eliminating the need to find an electrical outlet or use long extension cords
With the 1770 Series, you'll never miss critical power quality events—from fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, and voltage, current, and power measurements that let you understand your electrical system.
Automatic measurement recording
Whether you're doing a quick system check or a detailed power quality study, consistent data is key. The Fluke 1770 Series offers a unique automated measurement taking system that helps ensure you collect the right data every time, while giving you the flexibility to select and adjust certain parameters as needed. Over 500 power quality parameters are recorded by default and guided setup makes it easy to select the right parameters for the system you are working with. Logged data is instantly viewable, downloadable, and shareable with the Fluke Energy Analyze Plus software so you don't have to wait to finish your session before reviewing results or analyzing data
Best measurement confidence
The Fluke 1770 Series is a 2-in-1 device that combines the troubleshooting functionality of a power quality meter with the powerful analysis and logging capabilities of a standalone power quality analyzer—in one easy-to-use handheld device.
The 'Power Quality Meter' function gives you direct access to live data on the screen while in the field, so you can quickly identify potential problems when troubleshooting. The detailed 'Power Quality Logging and Analysis' function takes the hassle out of performing a power quality assessment by guiding you through the setup process to ensure you are capturing the right data every time. Combine these various measurement modes with the unique metering connection auto-correction function, and you can rest assured you won't have to go back for a second measurement—even if you weren't sure what to look for when you started.
Powerful analysis software with easy-to-generate reports
The Fluke 1770 Series Power Quality Analyzers are equipped with the powerful Fluke Energy Analyze Plus software. This software is designed to take the hassle out of other multi-purpose application software. Energy Analyze Plus helps you easily evaluate power quality data, without the need for lengthy training.
Energy Analyze Plus makes it easy to download, analyze, track and report on power quality and energy data. Quickly compare results to historical values, benchmark against industry norms, compare measured data to local conditions, and create a more complete picture of what's happening across your facility, even while data is still being collected. Energy Analyze Plus offers integrated support for the Fluke 1730, 1740, and 1770 Series of Energy Loggers and Power Quality Analyzers.
“In-workshop” and “in-the-field” setup and download via PC application software
- Simple data download using a USB memory stick, WiFi, LTE, Ethernet cable or USB cable
- Analyze every detail of energy consumption and power quality health status with automatic reports
- One-touch reporting creates standardized reports that comply with standards such as EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual or CSV compatible formats for use with third-party software
- Advanced analysis allows users to select recorded parameters and create highly customized measurement views for advanced data correlation
Power Quality
High speed voltage transient recording
Transients negatively affect a healthy system every day and their potential to damage your equipment should not be underestimated. Whether your system experiences impulsive or oscillating transients, the results can be catastrophic and result in problems ranging from insulation failure to total equipment failure. The Fluke 1775 and Fluke 1777 feature advanced transient recording technology to help you clearly identify high-voltage transient conditions, so you have the data you need to stop them. The Fluke 1775 Power Quality Analyzer has 1 MHz sampling capability to record fast transients, while the Fluke 1777 Power Quality Analyzer has 20 MHz sampling capability to record the fastest transients in high detail.
From conventional industrial systems to renewable energy systems to electric vehicles, we have the tools
The Fluke 1770 Series is designed to be safe and easy to use in any measurement environment. The 1770 Series lets you record a variable range of full power quality as well as high speed waveforms, high speed transients and higher frequency harmonics. Everything can be seen directly on the large high-resolution screen. With best-in-class CAT IV 600 V / CAT III 1000 V overvoltage ratings, this analyzer can be used in mains or downstream input receivers, measuring AC and DC inputs, as well as measuring harmonics up to 30 kHz. With the 1770 Series, you can rest assured that you will capture the data you need to make better maintenance decisions, whatever the task.
In accordance with international standards
The Fluke 1770 Series offers the best-in-class accuracy you expect from a Fluke Power Quality Analyzer in a package that meets IEC 61000-4-30 Class A next edition 3. In addition, the 1770 Series has been designed to meet the requirements of the upcoming Class A edition, to comply with EN 50160 and IEEE 519, so you are well prepared to address your future measurement needs.
Work where, when, and how you want
The situation on the ground is different every day. You need a power quality analyzer that you can always carry with you and work the way you need it. With a wide range of accessories and built-in features, the Fluke 1770 Series makes it easy to get the job done. The slim ergonomic design and integrated wrist strap make it easy to hold and the included hanging kit makes it easy to store your analyzer in the cabinet. The integrated internal power supply allows the unit to be powered directly from a rated circuit, while a 90-minute battery helps ensure you can still access and review data even when not connected to a live system.
Transfer data quickly and easily to your PC using USB C, USB A, Ethernet, Wi-Fi, or mobile network support options, depending on your needs. With the built-in GPS module and optional dual isolation antenna extension cable to amplify indoor GPS signals, you can easily synchronize your data with the time for more accurate troubleshooting and analysis.
Calculate current harmonic limits
When downloading data from the Fluke 1770 Series Power Quality Analyzer, the included Energy Analyze Plus software package can compare rated voltage and current harmonics statistical data against various standards, such as EN 50160 or IEEE 519. This is to determine if the data exceeds compliance limits. . With this advanced predictive maintenance feature, current harmonics can be spotted before distortions in voltage appear, so you can prevent unexpected failures or inappropriate situations and increase system uptime. With inverter-based loads and power generation increasing, keeping current harmonics in line is becoming increasingly important to ensure reliable power quality and avoid system downtime.
Automatic measurements. More flexibility. Better power quality troubleshooting.
Fluke 1770 Series Three-Phase Power Quality Analyzers eliminate the complexities of power quality logging, troubleshooting, and analysis. Engineered to be the faster, easier way to perform power quality studies, the 1770 Series offers automatic measurements, a straightforward user interface and setup, best-in-class specifications, and a simplified reporting platform. The instrument can also be powered directly from the measurement circuit, eliminating the need to find a power outlet or use a lengthy extension cord.
With the 1770 Series you’ll never miss a critical power quality event—from fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, as well as the voltage, current, and power measurements that enable you to characterize your electrical system.
Automatic measurement capture
Whether you’re performing a quick system check or a detailed power quality study, consistent data is key. The Fluke 1770 Series offers a unique automatic measurement capture system that helps ensure you’re collecting the right data every time, while still giving you the flexibility to select and adjust specific parameters as needed. More than 500 power quality parameters are captured by default and the guided setup makes it easy to select the right parameters for the system you’re working on. Logged data is instantly viewable, downloadable, and shareable with Fluke Energy Analyze Plus software so you never need to wait to finish a session before reviewing results or analyzing data.
Ultimate measurement confidence
The Fluke 1770 Series are 2-in-1 devices that combine the troubleshooting functionality of a power quality meter with the robust analysis and logging capabilities of a standalone power quality analyzer—in a single, easy-to-use, handheld device.
The ‘PQ Meter’ function gives you immediate access to live onscreen data in the field so you can quickly identify potential problems while troubleshooting. The detailed ‘PQ Logging and Analysis’ function eliminates the complexity of performing power quality studies by guiding you through the setup process ensuring you’re capturing the right data every time. Couple these measurement modes with a unique measurement connection autocorrect function and you can be confident that you never need to worry about going back for a second measurement—even if you were unsure about what to look for when you started.
Powerful analysis software with easy-to-create reports
Fluke 1770 Series Power Quality Analyzers come standard with the powerful Fluke Energy Analyze Plus software, designed to eliminate the hassles found with other multi-purpose application software. Energy Analyze Plus helps you evaluate power quality data right out of the box and without extensive training.
Energy Analyze Plus makes downloading, analyzing, tracking, and reporting power quality and energy data easier than ever. Quickly compare results to historical values, benchmark against industry norms, compare measured data to local conditions, and create a more complete picture of what’s occurring across your facility, even as the data is still being collected. Energy Analyze Plus offers unified support for the Fluke 1730, 1740, and 1770 Series of Energy Loggers and Power Quality Analyzers.
“In-workshop” and “in-the-field” setup and download through PC application software
Simple data downloads using USB memory stick, WiFi, LTE, wired Ethernet, or USB cable
Analyze every measured detail of energy consumption and power quality state-of-health with automated reporting
One-touch reporting creates standardized reports conforming to standards like EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual compatible format or CSV for use with third-party software
Advanced analysis allows the user to choose any available logged parameter and create a highly customized view of measurements for advanced data correlation
High-speed voltage transient capture
Transients negatively impact otherwise healthy systems every day and their potential to damage your equipment can’t be underestimated. Whether your system is experiencing impulsive or oscillatory transients, the results can be devastating and cause problems ranging from insulation failures to total equipment failures. The Fluke 1775 and Fluke 1777 incorporate advanced transient capture technology to help you clearly identify high-speed voltage transients, so you have the data you need to stop them in their tracks. The Fluke 1775 Power Quality Analyzer has 1MHz sampling capability to capture fast transients, while the Fluke 1777 Power Quality Analyzer has 20MHz sampling capability to capture the fastest transients in high detail.
Compliant to international standards
The Fluke 1770 Series offers the best-in-class accuracy you’ve come to expect from a Fluke Power Quality Analyzer in a future IEC 61000-4-30 Class A edition 3 compliant package. On top of that, the 1770 Series has been engineered to meet the future requirements of Class A edition, for conformance to EN 50160 and IEEE 519, so you’ll be prepared to tackle tomorrow’s measurement requirements, today.
Fluke 1770 Series Three-Phase Power Quality Analyzers eliminate the complexities of power quality logging, troubleshooting, and analysis. Engineered to be the faster, easier way to perform power quality studies, the 1770 Series offers automatic measurements, a straightforward user interface and setup, best-in-class specifications, and a simplified reporting platform. The instrument can also be powered directly from the measurement circuit, eliminating the need to find a power outlet or use a lengthy extension cord.
With the 1770 Series you’ll never miss a critical power quality event—from fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, as well as the voltage, current, and power measurements that enable you to characterize your electrical system.
Automatic measurement capture
Whether you’re performing a quick system check or a detailed power quality study, consistent data is key. The Fluke 1770 Series offers a unique automatic measurement capture system that helps ensure you’re collecting the right data every time, while still giving you the flexibility to select and adjust specific parameters as needed. More than 500 power quality parameters are captured by default and the guided setup makes it easy to select the right parameters for the system you’re working on. Logged data is instantly viewable, downloadable, and shareable with Fluke Energy Analyze Plus software so you never need to wait to finish a session before reviewing results or analyzing data.
Ultimate measurement confidence
The Fluke 1770 Series are 2-in-1 devices that combine the troubleshooting functionality of a power quality meter with the robust analysis and logging capabilities of a standalone power quality analyzer—in a single, easy-to-use, handheld device.
The ‘PQ Meter’ function gives you immediate access to live onscreen data in the field so you can quickly identify potential problems while troubleshooting. The detailed ‘PQ Logging and Analysis’ function eliminates the complexity of performing power quality studies by guiding you through the setup process ensuring you’re capturing the right data every time. Couple these measurement modes with a unique measurement connection autocorrect function and you can be confident that you never need to worry about going back for a second measurement—even if you were unsure about what to look for when you started.
Powerful analysis software with easy-to-create reports
Fluke 1770 Series Power Quality Analyzers come standard with the powerful Fluke Energy Analyze Plus software, designed to eliminate the hassles found with other multi-purpose application software. Energy Analyze Plus helps you evaluate power quality data right out of the box and without extensive training.
Energy Analyze Plus makes downloading, analyzing, tracking, and reporting power quality and energy data easier than ever. Quickly compare results to historical values, benchmark against industry norms, compare measured data to local conditions, and create a more complete picture of what’s occurring across your facility, even as the data is still being collected. Energy Analyze Plus offers unified support for the Fluke 1730, 1740, and 1770 Series of Energy Loggers and Power Quality Analyzers.
“In-workshop” and “in-the-field” setup and download through PC application software
Simple data downloads using USB memory stick, WiFi, LTE, wired Ethernet, or USB cable
Analyze every measured detail of energy consumption and power quality state-of-health with automated reporting
One-touch reporting creates standardized reports conforming to standards like EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual compatible format or CSV for use with third-party software
Advanced analysis allows the user to choose any available logged parameter and create a highly customized view of measurements for advanced data correlation
High-speed voltage transient capture
Transients negatively impact otherwise healthy systems every day and their potential to damage your equipment can’t be underestimated. Whether your system is experiencing impulsive or oscillatory transients, the results can be devastating and cause problems ranging from insulation failures to total equipment failures. The Fluke 1775 and Fluke 1777 incorporate advanced transient capture technology to help you clearly identify high-speed voltage transients, so you have the data you need to stop them in their tracks. The Fluke 1775 Power Quality Analyzer has 1MHz sampling capability to capture fast transients, while the Fluke 1777 Power Quality Analyzer has 20MHz sampling capability to capture the fastest transients in high detail.
Compliant to international standards
The Fluke 1770 Series offers the best-in-class accuracy you’ve come to expect from a Fluke Power Quality Analyzer in a future IEC 61000-4-30 Class A edition 3 compliant package. On top of that, the 1770 Series has been engineered to meet the future requirements of Class A edition, for conformance to EN 50160 and IEEE 519, so you’ll be prepared to tackle tomorrow’s measurement requirements, today.
The three models of the new 170 Series are the new benchmark for common multimeters. All three set the standard with their combination of precision, features, ease of use, safety and reliability
Use the Fluke 568 Ex for intrinsically safe temperature measurements anywhere in the world
The Fluke 568 Ex Intrinsically Safe Infrared Thermometer is certified by major rating bodies for use in Class I Div. 1 and Div. 2 or Zone 1 and 2 hazardous environments anywhere in the world. Whether you work in petroleum, chemical, oil and gas, or pharmaceutical environments, the 568 Ex allows you to carry the most trusted name in test tools into most Ex-rated areas around the globe. The simple, three-button on-screen menu interface is quick to use and makes even complex measurements easy. It takes just a few pushes of a button to adjust emissivity, record data, or turn on and off alarms. The 50:1 distance-to-spot ratio allows you to measure smaller objects from further away. And it also is compatible with K-type probes for contact measurements. Either way, you can count on the rugged, ergonomic design to stand up to tough conditions.
Other useful features:
- Instantly alerts you to measurements outside of set limits with audible and visual alarms
- Provides with 1% measurement accuracy
- Comes with thermocouple K bead probe and two-year warranty -30-
- Features a rugged, easy-to-use, ergonomic design that stands up to tough industrial, electrical, and mechanical environments
- Works with mini-connector K-type thermocouples
- Allows easy access to advanced features with soft-key buttons and graphical display
- Captures up to 99 points of data for quick downloading to a PC through the USB connection
- Powered by two AA batteries
- Allows you to confidently measure a wide variety of surfaces with adjustable emissivity and built-in materials table
- Easily adapts to lighting conditions with a two-level backlight
The Fluke 568 Ex Intrinsically Safe Infrared Thermometer is certified by major rating bodies for use in Class I Div. 1 and Div. 2 or Zone 1 and 2 hazardous environments anywhere in the world. Whether you work in petroleum, chemical, oil and gas, or pharmaceutical environments, the 568 Ex allows you to carry the most trusted name in test tools into most Ex-rated areas around the globe. The simple, three-button on-screen menu interface is quick to use and makes even complex measurements easy. It takes just a few pushes of a button to adjust emissivity, record data, or turn on and off alarms. The 50:1 distance-to-spot ratio allows you to measure smaller objects from further away. And it also is compatible with K-type probes for contact measurements. Either way, you can count on the rugged, ergonomic design to stand up to tough conditions.
Other useful features:
- Instantly alerts you to measurements outside of set limits with audible and visual alarms
- Provides with 1% measurement accuracy
- Comes with thermocouple K bead probe and two-year warranty -30-
- Features a rugged, easy-to-use, ergonomic design that stands up to tough industrial, electrical, and mechanical environments
- Works with mini-connector K-type thermocouples
- Allows easy access to advanced features with soft-key buttons and graphical display
- Captures up to 99 points of data for quick downloading to a PC through the USB connection
- Powered by two AA batteries
- Allows you to confidently measure a wide variety of surfaces with adjustable emissivity and built-in materials table
- Easily adapts to lighting conditions with a two-level backlight
Fluke-572-2 High Temperature Infrared Thermometer measures temperatures up to 900°C
The Fluke 572-2 High-Temperature Infrared Thermometer is the ideal tool for high-temperature industrial environments all around the world. Whether you work in power utility, metal refining and smelting, glass, cement or petrochemical environments, the 572-2 offers the rugged performance accuracy you need to get the job done, backed by the most trusted name in test tools. The simple, three-button on-screen menu interface saves time and makes even complex measurements easy. With just a few pushes of a button you can adjust emissivity, start data logging, or turn on and off alarms. The 60:1 distance-to-spot ratio with dual laser sighting helps pinpoint the target fast, making it easier to measure small objects from a long distance.
Other useful features:
- Audible and visible alarms for rapid detection of high and low temperatures outside the limits
- Stores up to 99 data sets for review and analysis
- Powered by two, standard AA batteries -30-
- Presents infrared and thermocouple temperatures on a bright backlit display
- Is compatible with standard mini-connector K-type thermocouples, including ones you already own and have installed
- Features last reading Hold (20 seconds)
The Fluke 572-2 High-Temperature Infrared Thermometer is the ideal tool for high-temperature industrial environments all around the world. Whether you work in power utility, metal refining and smelting, glass, cement or petrochemical environments, the 572-2 offers the rugged performance accuracy you need to get the job done, backed by the most trusted name in test tools. The simple, three-button on-screen menu interface saves time and makes even complex measurements easy. With just a few pushes of a button you can adjust emissivity, start data logging, or turn on and off alarms. The 60:1 distance-to-spot ratio with dual laser sighting helps pinpoint the target fast, making it easier to measure small objects from a long distance.
Other useful features:
- Audible and visible alarms for rapid detection of high and low temperatures outside the limits
- Stores up to 99 data sets for review and analysis
- Powered by two, standard AA batteries -30-
- Presents infrared and thermocouple temperatures on a bright backlit display
- Is compatible with standard mini-connector K-type thermocouples, including ones you already own and have installed
- Features last reading Hold (20 seconds)
Fluke 62 Max Infrared Thermometer delivers single-laser targeting accuracy
The Fluke 62 MAX Infrared thermometer delivers many of the features of the Fluke 62 MAX+, but features a single laser and 10:1 distance to spot ratio. You can use the Fluke 62 MAX to perform non-contact temperature measurements on transformers, motors, pumps, panels, breakers, compressors, duct, steam lines, valves, and vents. It is small in size and extremely easy to use. The single laser helps you pinpoint the target for more accurate readings and makes it easier to measure temperatures in hard to reach areas. With its IP54 rating for dust and water resistance you can rely the Fluke 62 MAX to deliver accurate, repeatable temperature measurements, rain or shine, in even the dirtiest and dustiest industrial sites. And it’s rugged enough to take a 3-meter drop so no worries even if you work from a ladder.
Other useful features:
- High and low alarms for rapid detection of temperatures outside the limits
- Powered by a single, standard AA battery.
- Comes with a three-year warranty -30-
- Withstands a 3 m (9.8 ft.) drop
- Offers small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
- Features a large, backlit display to make data easier to read, even in dark areas.
- Displays Min/Max/Avg/Dif: the minimum, maximum or average temperature, or the difference between two measurements
The Fluke 62 MAX Infrared thermometer delivers many of the features of the Fluke 62 MAX+, but features a single laser and 10:1 distance to spot ratio. You can use the Fluke 62 MAX to perform non-contact temperature measurements on transformers, motors, pumps, panels, breakers, compressors, duct, steam lines, valves, and vents. It is small in size and extremely easy to use. The single laser helps you pinpoint the target for more accurate readings and makes it easier to measure temperatures in hard to reach areas. With its IP54 rating for dust and water resistance you can rely the Fluke 62 MAX to deliver accurate, repeatable temperature measurements, rain or shine, in even the dirtiest and dustiest industrial sites. And it’s rugged enough to take a 3-meter drop so no worries even if you work from a ladder.
Other useful features:
- High and low alarms for rapid detection of temperatures outside the limits
- Powered by a single, standard AA battery.
- Comes with a three-year warranty -30-
- Withstands a 3 m (9.8 ft.) drop
- Offers small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
- Features a large, backlit display to make data easier to read, even in dark areas.
- Displays Min/Max/Avg/Dif: the minimum, maximum or average temperature, or the difference between two measurements
From the control room to the factory floor, the Fluke 80 Series digital multimeter has earned a reputation as the digital multimeter that industrial technicians trust. When productivity suffers, the Fluke 80 Series provides the accuracy and advanced troubleshooting capabilities you need to solve problems fast.
Use the low pass filter function to accurately measure voltage and frequency on electrically noisy equipment such as variable speed motor drives. Use the peak capture function to detect occasional faults and switch as fast as 250 microseconds (µs).
And work with confidence. The Input Alert function provides an audio alert against misuse of the input plug. The Fluke 80 Series multimeters have been tested separately for use in CAT IV 600 V/CAT III 1000 V environments. The Series can withstand impulses in excess of 8000 V and reduce the risks associated with surges and surges.
At Fluke, our ideas come straight from the workplace. We work with users like you to build test kits that do the job you want them to do for as long as you need them—and give you full value. We design and manufacture the Fluke 80 Series multimeters in the U.S.A. The 80 Series is backed by a limited lifetime warranty. And we back it with a limited lifetime warranty so you can work smarter, faster, and safer.
Use the low pass filter function to accurately measure voltage and frequency on electrically noisy equipment such as variable speed motor drives. Use the peak capture function to detect occasional faults and switch as fast as 250 microseconds (µs).
And work with confidence. The Input Alert function provides an audio alert against misuse of the input plug. The Fluke 80 Series multimeters have been tested separately for use in CAT IV 600 V/CAT III 1000 V environments. The Series can withstand impulses in excess of 8000 V and reduce the risks associated with surges and surges.
At Fluke, our ideas come straight from the workplace. We work with users like you to build test kits that do the job you want them to do for as long as you need them—and give you full value. We design and manufacture the Fluke 80 Series multimeters in the U.S.A. The 80 Series is backed by a limited lifetime warranty. And we back it with a limited lifetime warranty so you can work smarter, faster, and safer.
The 87V MAX contains all the trusted features of the most popular DMM in use today, the Fluke 87V, with many more extras.
Withstands drops of up to 4 meters (13 feet)
Fluke's most rugged digital multimeter. The 87V MAX features a rugged case for industrial use and a removable holster. This holster also doubles as a test probe holder for one-handed operation.
IP67 rated
Completely waterproof and dustproof, to work reliably anywhere you need to work.
Heat and cold resistant
This meter has a longer operating temperature range from -40 °C (for up to 20 minutes) to +55 °C.
Another product highlight
- True-rms ac current and voltage for accurate measurements on non-linear signals
- Measures up to 1000 V ac and dc
- Measures up to 10 A (20 A for 30 seconds)
- Frequency up to 200 kHz
- Built-in thermometer allows you to freely take temperature readings without having to carry a separate instrument
- Min/Max/Average recording, plus 250 µs Peak min-max to record variations automatically
- Unique function for accurate measurement of voltage and frequency in variable frequency motor drives and other electrically noisy equipment
- Large digit display, 2 brightness levels, white backlight, and backlit keypad keys for better visibility
- High resolution 19,999 digit mode display
- Long lasting battery life (800 hours)
Withstands drops of up to 4 meters (13 feet)
Fluke's most rugged digital multimeter. The 87V MAX features a rugged case for industrial use and a removable holster. This holster also doubles as a test probe holder for one-handed operation.
IP67 rated
Completely waterproof and dustproof, to work reliably anywhere you need to work.
Heat and cold resistant
This meter has a longer operating temperature range from -40 °C (for up to 20 minutes) to +55 °C.
Another product highlight
- True-rms ac current and voltage for accurate measurements on non-linear signals
- Measures up to 1000 V ac and dc
- Measures up to 10 A (20 A for 30 seconds)
- Frequency up to 200 kHz
- Built-in thermometer allows you to freely take temperature readings without having to carry a separate instrument
- Min/Max/Average recording, plus 250 µs Peak min-max to record variations automatically
- Unique function for accurate measurement of voltage and frequency in variable frequency motor drives and other electrically noisy equipment
- Large digit display, 2 brightness levels, white backlight, and backlit keypad keys for better visibility
- High resolution 19,999 digit mode display
- Long lasting battery life (800 hours)
