Ideal for accurately measuring internal and external thread forms. Manufactured from hardened and polished steel, the blades are precision milled for optimum accuracy. Enclosed in a steel case.



Featrures and Benefits

• Hardened and polished steel for increased durability

• With precision milled blades for accuracy

• Used to internal and external thread forms

• Enclosed in a steel case for easy storage and portability

Fluke 750P31 Offers



Fluke 750P Series Pressure Modules are easy to use. To measure pressure, connect the pressure module to a pressure source or hand pump and then connect the pressure module cable to the calibrator. Apply pressure from the pressure source and it is displayed digitally on the calibrator. At the touch of a button, the pressure may be displayed in up to 11 different engineering units. When used with the 750 Series Documenting Process Calibrators, pressure readings can be date/time stamped and stored electronically for later retrieval. This saves time, eliminates errors, and supports F85compliance with quality standards and regulations.



Features

- Parameter/Range:0 to 10000 psi (0 to 700 bar)

- Burst Rating6:2x

- Hi Side Media2:316 SS

- Lo Side Media2:N/A

- Reference Uncertainty4:± 0.0175%

- Total Uncertainty 1-year (15-35°C):± 0.035%

- Total Uncertainty 1-year1:± 0.045%

- Total Uncertainty 6-month (15-35°C):± 0.03%

- Total Uncertainty 6-month1:± 0.04%

Portable multi-function calibrator simplifies calibration work



Whether you're calibrating instruments, troubleshooting a problem, or running routine maintenance, the Fluke 754 with HART® communication can help you get the job done faster. It does many different tasks quickly and it's the only process calibrator you need to carry. This rugged, reliable, integrated communicating calibrator is ideal for calibrating, maintaining, and troubleshooting HART smart transmitters and other instrumentation.



Measurement and source capabilities:

- AC/DC voltage

- mA loop w/ 24V loop power

- Pressure

- Thermocouples & RTDs

- Frequency

- Resistance



Enhanced process calibrator operation



With the bright white dual display, you’ll be able to read both sourced and measured parameters simultaneously. The rechargeable Li-Ion battery offers up to 10 hours uninterrupted usage allowing you to complete one task after another without needing to stop, and also includes direct AC power capabilities if needed. Finally, communicate with HART smart digital transmitters directly through the mA measurement jacks for seamless calibration with fewer connections.



Do more, with less

The 754 does the work of several tools. It sources, simulates and measures pressure, temperature, and electrical signals with one rugged, hand-held device. The powerful built-in HART interface can perform nearly all day-to-day tasks you now perform with a separate digital communicator. It can handle fast-pulsed RTD transmitters and PLCs, with pulses as short as 1 ms. The 754 also measures/sources pressure using any of the Fluke 750P Series Pressure Modules as a reference and boasts many additional features like:

- Custom auto-step and ramping

- Custom units

- User-entered values during test

- One-point and two-point switch testing

- Square root DP flow testing

- Programmable measurement delay



Download procedures, lists, and instructions



The 754 is a power multifunction documenting calibrator that you can use to download procedures, lists, and instructions created with software, or upload data for printing, archiving, and analysis. The tool can hold up to a full week of downloaded procedures and calibration results and offers compatibility with many asset management software. Users can also create and run automated as-found or as-left procedures to satisfy quality programs or regulations, and records and documents results.



For documentation, the 754 automates calibration procedures and captures your data. And, of course, it helps you meet rigorous standards like ISO 9000, FDA, EPA, and OSHA regulations. Plus, the graphical screen, Li-Ion battery for longer life, USB port, and accessories help you work smarter and faster.



To create a seamless/paperless calibration management system consider adding Fluke DPCTrack2 Calibration Management software.

Compact smart pressure solution for on site or field



The Fluke 730G Smart Digital Pressure Calibrator combines the performance of a precision test gauge with the power of a loop calibrator and includes internal HART communication capabilities. When used with a pressure test pump, the Fluke 730G makes a highly efficient and highly accurate calibrator that can test pressure gauges, pressure switches and pressure transmitters, making it ideal for workshop instruments, measuring laboratories and pressure laboratories.

- Built-in HART communication: The integrated HART communication functionality is easy to use and you can customize HART directly, with no additional adjustment tools needed.

- Precision Pressure and Current Measurement: The 730G series provides high precision 0.02% pressure measurement accuracy and 0.01% flow measurement accuracy to meet laboratory pressure setting requirements and achieve accurate pressure calibration results.

- Intuitive operation and ease of use: High-end LCD screen and dual jack design provide a more practical and efficient user experience.

- Paperless testing and reporting: The optional 730G/PCSW management software enables paperless testing giving you the ability to automatically generate test reports and document results.



Fluke 730G/PCSW Software

- Paperless pressure calibration management: Record calibration data, perform calibration tests automatically and generate calibration reports.

- Asset management: Easily manage proven equipment and pressure standards.

- Supported pressure devices include: analog pressure gauges, digital pressure gauges, pressure transmitters, pressure sensors and pressure switches.



Increase your pressure testing capabilities with the



Fluke-700PTPK Pneumatic test pump kit:

- Combine with Fluke-730G Series Gauge, 1000 psi (69 bar) or less

- Generates pressures up to 600 psi (40 bar) with the 700PTP-1 test pump

- Connect the 730G Series meter directly to the included PTP-1 hand pump

- Includes hoses and adapters to connect the device to the pressure device to be tested

- The hardened carrying case protects the pump and gauge and allows the gauge to remain connected to the pump



Fluke-700HTPK Hydraulic Test Pump Kit

- Combine with Fluke-730G Series Gauge, 1000 psi (69 bar) or higher

- Generates pressure up to 10000 psi (690 bar) with 700HTP-2 test pump

- Connect the 730G Series Meter directly to the HTP-2 hand pump

- Includes a 700HTH-1 hose and adapter for connecting to the pressure device to be tested.

- The hardened carrying case protects the pump and gauge and allows the gauge to remain connected to the pump
