Manufactured from high quality polished steel. Ground finished points, a fine adjusting screw is mounted across the legs for setting the distance between the two points. A circular spring bow joins the legs, with a knurled extension attached for use when pivoting the dividers. Dividers are used for scribing arcs and circles, a light centre punch mark on the work keeps the pivot leg in the centre while marking.



Features and Benefits

• High quality polished steel with ground finished points

• Adjusting screw mounted across the legs for setting distance between points

• A light centre punch mark on the work keeps pivot leg in the centre while marking

• Ideal for use in scribing arcs and circle applications

Fluke ii500 Acoustic Imager with LeakQ™: Detect, Locate, and Capture Gas Leaks
The Fluke ii500 Acoustic Imager, equipped with LeakQ™ technology, empowers maintenance teams to detect and locate gas leaks efficiently. Designed for ease of use, it requires no specialized training. Even during peak production periods, teams can effectively identify gas and vacuum leaks. The ii500's advanced acoustic leak detection technology isolates leak sound frequencies, making leaks visible even in noisy environments.

Key features
• Ready-to-Use: The Fluke ii500 is ready out of the box. Its rugged, ergonomic design ensures easy handling, while the large 7" LCD display allows for clear leak visualization.
• Quick Detection: Even users with minimal experience can start detecting leaks within minutes. The tool estimates relative leak size and cost, incorporating a new distance-estimation feature and the 1-10 LeakQ™ severity index.
• SoundMap™ Overlay: The 7" LCD touchscreen overlays a SoundMap™ on visual images, facilitating rapid leak location identification.
• Intuitive Interface: Easily isolate leak sound frequencies and filter out background noise.
• Tagging and Organization: Use image and video tagging, annotation, and folders for efficient organization.
• Leak Sizing: Prioritize repairs based on relative leak size.
• Collaboration: The reporting tool allows sharing of visuals, tagging, and notes with team members and repair personnel.

Keep yourself safe. Find hidden problems faster. Put the paperwork down.



Fluke Connect + Fluke's 1587 FC Insulation Multimeter helps you identify tough problems, fix, and wirelessly communicate your work quickly and easily - all at a safe distance.



Add diagnostics with Fluke Connect

The Fluke 1587 FC is Fluke Connect-enabled so you can download the free Fluke Connect® Measurements app to your smartphone and gain additional functions, including:

- Safety first. Keep yourself out of harm’s way by monitoring your test measurements remotely.

- Prove your job is done right by quickly seeing and sharing measurement results wirelessly with your smartphone.

- Quickly find problems by saving and comparing measurements over time on a wireless device.

- PI/DAR timed ratio tests with TrendIt™ graphs to identify moisture and contaminated insulation problems faster

- Memory storage through Fluke Connect that saves measurements to your phone or the cloud and eliminates the need to write down results. Reduces errors and saves data for historical tracking over time

- Temperature compensation to establish accurate baselines and relevant historical comparisons

- Historical tracking and trending of assets to identify insulation degradation over time and allow real-time decisions to be made in the field with Fluke Connect® Assets (sold separately)

- Provides memory storage through Fluke Connect Measurements to eliminate the need to write down results

- Includes live circuit detection to prevent insulation test if voltage >30 V is detected

- Supports historical tracking and asset trending of assets to identify degradation over time with Fluke Connect® Assets (sold separately)

- Incorporates VFD low-pass filter for accurate variable frequency motor drive measurements

- Includes auto-discharge of capacitive voltage for added user protection

- Measures ac/dc voltage, dc millivolts, ac/dc milliamps, resistance, and continuity

- Includes capacitance, diode test, temperature, min/max, frequency measurements and insulation test smoothing reading

- Automatically powers off to save battery power

- Comes with remote probe, test leads, alligator clips, K-type thermocouple, hard case, and three-year warranty.

When it's not just infrared.



Introducing Fluke infrared cameras, the first with full radiometry technology – the RSE series. Packed with advanced features and plug-in software for MATLAB® and LabVIEW® , these tools are ideal for continuous streaming and analysis of infrared data.



Designed for your research, science and engineering needs, enhance your testing and quality assurance procedures by attaching the RSE600 to your workstation. Continuously stream up to 60 frames per second of data directly to your computer to monitor minute temperature differences, as well as analyze remote video frame-by-frame from the SmartView® desktop software . Get an even more perfect screen with add-on lenses to target different applications (analyzing from a distance, or getting detailed close-ups).



Don't just look at the heat. Stream, measure and analyze its power as well.



With plug-ins for MATLAB® and LabVIEW® , the RSE Infrared Camera is perfect for testing and development. Looking for more robust software to monitor and archive processing manufacturing data 24/7? We recommend the ThermoView® series from Fluke Process Instruments. Check out a quick comparison
