Electrical & Lighting

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NNP19940031
Type of Light Source : LED
Power Input : 120W
System Lumen Output : 15600 lm
Power Voltage : 110-240V
Lifetime : 50000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 60deg.
Beam Angle : 60deg.
IP Rating : 65
Ambient Temperature : -40 - 50°C
Dimensions : 304mmx310mmx296mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NNP19941031
Type of Light Source : LED
Power Input : 200W
System Lumen Output : 26000 lm
Power Voltage : 110-240V
Power Factor : 0.90
Lifetime : 50000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 60deg.
Beam Angle : 60deg.
IP Rating : 65
Ambient Temperature : -40 - 50°C
Dimensions : 304mmx473mmx296mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12317LD2031
Type of Light Source : LED
Power Input : 251W
System Lumen Output : 35800 lm
Power Voltage : 200-242V
Power Factor : 0.90
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 77deg.
Beam Angle : 27deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 422mmx534mmx340mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12337LD2031
Type of Light Source : LED
Power Input : 267W
System Lumen Output : 40400 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 64deg.
Beam Angle : 53deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 422mmx534mmx340mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12347LD2031
Type of Light Source : LED
Power Input : 264W
System Lumen Output : 41000 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 60deg.
Beam Angle : 54deg.
IP Rating : 75deg.
Ambient Temperature : -20 - 35°C
Dimensions : 422mmx534mmx340mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12517LD2031
Type of Light Source : LED
Power Input : 442W
System Lumen Output : 63200 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 77deg.
Beam Angle : 27deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx534mmx500mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12527LD2031
Type of Light Source : LED
Power Input : 462W
System Lumen Output : 68900 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 70deg.
Beam Angle : 53deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx534mmx500mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12537LD2031
Type of Light Source : LED
Power Input : 462W
System Lumen Output : 68000 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 64deg.
Beam Angle : 75deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx534mmx500mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12547LD2031
Type of Light Source : LED
Power Input : 432W
System Lumen Output : 65500 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 54deg.
Beam Angle : 34deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx534mmx500mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12717LD2031
Type of Light Source : LED
Power Input : 707W
System Lumen Output : 101000 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 77deg.
Beam Angle : 27deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx537mmx720mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12727LD2031
Type of Light Source : LED
Power Input : 706W
System Lumen Output : 106700 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 64deg.
Beam Angle : 75deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx537mmx720mm
Body : ADC

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12727LD2031
Type of Light Source : LED
Power Input : 706W
System Lumen Output : 106700 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 64deg.
Beam Angle : 75deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx537mmx720mm
Body : ADC
