TCGT turning inserts feature a CVD coated substrate providing an excellent general purpose grade for medium roughing on steels, stainless and cast irons.

Features and Benefits
• CVD MT-TiCN-Al2O3-TiN coating for increased heat and wear resistance
• Tough substrate for increased cutting strength
• Versatile usage can be used in a range of applications from roughing to finishing
• PF chipbreaker for good chip flow

Typical Applications
• General purpose
• Medium roughing
• Finishing
• Steel
• Stainless steel
• Cast iron
Finish.

Standards
• Insert Grade QX5020
• (ISO P10-P35 M10-M30 K10-K30)

Cylindrical-End Cutting
All sizes are nominal with a 6mm shank unless other wise stated.

Cut Numbers:

Cut 3 - Rapid Cut.
for use on softer non ferrous and plastic materials, i.e aluminium, fibreglass, plastics, hard rubber and zinc alloy,

Cut 6 - Double Cut.
Crosscut and double cut to improve control and chipbreaks. Manufactured from high grade tungsten carbide for general-purpose use.

Cut 9 - Chipbreaker
Chipbreaker fast stock removal for improved control and reduced chips for use on hard materials, i.e. steel alloy 50RC, 60RC, carbon and cast iron.

Suitable for deburring and polishing of cast iron, cast steel, carbon steel, alloy steel and stainless steel etc.
up to HRC65 hardness.

Please note:
• Work piece and tools should always be steady and well supported.
• Carbide burrs are not suitable for 'milling' large amounts of material, they are for light stock removal and high revolutions 'LOW FEED - HIGH SPEED'.
• Always ensure that at least 70% of the shank length is clamped by the collet or chuck of the tool being used.
• Always ensure that the tool is rated to the recommended operating speed of the burr.

Set of various style burrs packaged in a handy pocket 'glasses case' style plastic holder. Ideal for the shop floor workman with various de-burring tasks. Suitable for precision grinding of carbide gems, ceramics, tough alloys, cermets, tool steels etc

Features and Benefits
• Diamond coated for improved hardness
• Excellent performance with precise grinding

Contents
• Assorted sizes of ball shape
• Cylindrical
• Ball nose cylindrical
• Tree shape and conical


Specifications
• Diamond grip mesh is 120/140
• recommended operating speeds 15,000 - 30,000
• Up to 4.5mm diameter
• Overall length 45mm
• 3mm shank

Typical Applications
• Grinding
• Carbide gems
• Glass
• Ceramics
• Tough alloys
• Cermets
• Tool steels

The Kennedy® Carbide Burr Set features eight heads with varying nose shapes suitable for use on hard materials such as steel alloys, carbon and cast iron.

Features and Benefits
• Durable carbide construction
• 8-piece set with varying nose shapes to suit the preferred application
• Features a handy carry case for easy storage and tool identification
• Shank diameter: 6mm
• Max. speed (rpm): 40,000
• Chipbreaker (Cut 9): for use on cast iron, carbon steel, alloy steel 50RC and 60RC

Contents
• 1x C shape ball nosed cylinder 9.6 x 19mm
• 1x E shape oval 9.6 x 16mm
• 1x F shape ball nosed tree 9.6 x 19mm
• 1x G-shape pointed tree 9.6 x 19mm
• 1x A shape cylinder without end cut 9.6 x 19mm
• 1x C shape ball nosed cylinder 12.7 x 25mm
• 1x D shape ball 12.7 x 11mm
• 1x F shape ball nosed tree 12.7 x 25mm

Typical Applications
• Milling
• Deburring

Warnings
• Not suitable for milling large amounts of material
