Elbow Connector to Male Parallel


Quick and simple tube insertion. Compact lightweight design with a well proven tube retaining system. Tapered threads have a re-usable thread seal and parallel threads have a rubber washer. Main body manufactured from nickel plated brass, acetal resin, PBT with a stainless steel retaining ring, nitrile tube seal and acetal resin tube release collar.


Pressure range: -0.9bar min to +10bar max. Temp range: -20°C min to +70°C max. Tube suitability: Nylon, polyurethane.

This 1/2" impact wrench guarantees the correct reverse torque up to 670 ft.lbs / 900 Nm for all general maintenance and tire changing applications. The twin hammer impact mechanism and metal housing ensure excellent durability. This model belongs to the CP7736 series which is composed of 2 models: 1/2" short anvil and 1/2" long anvil (2" anvil).

A range designed for general maintenance with its Side-2-Side reverse / forward technology. Its twin hammer impact mechanism and its composite housing offer high durability. High productivity is ensured with a torque of 450 ft.lbs / 610 Nm. The CP7729/CP7739 series is composed of 2 models: 3/8" short anvil and 1/2" short anvil.

SR500
Highly effective, durable and compact speed ratchet, perfect for a wide range of applications.

Technical Information
• 1/2" square drive,
• M13 bolt capacity.
• Sound pressure Level: 89 db(A)
• Sound Power level: 89 db(A)
• Vibration: 4.0 m/s²

Features and Benefits
• Ball type retainer
• Disc type reversing action
• Very compact, lightweight design
• Ideal for automotive work
• front exhaust

Notes
• Free speed: 150rpm.
• Air inlet thread: 1/4" NPT.
• Minimum air hose size (ID): 10mm (3/8").
• Air pressure: 6.2bar/90psi.
• Air consumption: 4cfm* (1.88 l/s).
• Torque: 68 Nm
• Overall length: 265 mm.

*Based on a 15 second cycle per minute average use.
