Compact smart pressure solution for on site or field



The Fluke 730G Smart Digital Pressure Calibrator combines the performance of a precision test gauge with the power of a loop calibrator and includes internal HART communication capabilities. When used with a pressure test pump, the Fluke 730G makes a highly efficient and highly accurate calibrator that can test pressure gauges, pressure switches and pressure transmitters, making it ideal for workshop instruments, measuring laboratories and pressure laboratories.

- Built-in HART communication: The integrated HART communication functionality is easy to use and you can customize HART directly, with no additional adjustment tools needed.

- Precision Pressure and Current Measurement: The 730G series provides high precision 0.02% pressure measurement accuracy and 0.01% flow measurement accuracy to meet laboratory pressure setting requirements and achieve accurate pressure calibration results.

- Intuitive operation and ease of use: High-end LCD screen and dual jack design provide a more practical and efficient user experience.

- Paperless testing and reporting: The optional 730G/PCSW management software enables paperless testing giving you the ability to automatically generate test reports and document results.



Fluke 730G/PCSW Software

- Paperless pressure calibration management: Record calibration data, perform calibration tests automatically and generate calibration reports.

- Asset management: Easily manage proven equipment and pressure standards.

- Supported pressure devices include: analog pressure gauges, digital pressure gauges, pressure transmitters, pressure sensors and pressure switches.



Increase your pressure testing capabilities with the



Fluke-700PTPK Pneumatic test pump kit:

- Combine with Fluke-730G Series Gauge, 1000 psi (69 bar) or less

- Generates pressures up to 600 psi (40 bar) with the 700PTP-1 test pump

- Connect the 730G Series meter directly to the included PTP-1 hand pump

- Includes hoses and adapters to connect the device to the pressure device to be tested

- The hardened carrying case protects the pump and gauge and allows the gauge to remain connected to the pump



Fluke-700HTPK Hydraulic Test Pump Kit

- Combine with Fluke-730G Series Gauge, 1000 psi (69 bar) or higher

- Generates pressure up to 10000 psi (690 bar) with 700HTP-2 test pump

- Connect the 730G Series Meter directly to the HTP-2 hand pump

- Includes a 700HTH-1 hose and adapter for connecting to the pressure device to be tested.

- The hardened carrying case protects the pump and gauge and allows the gauge to remain connected to the pump

Key features
Ultra-cool dry-block calibrator with best-in-class stability

The Fluke 9190A Ultra-Cool Field Metrology Well is the most accurate and stable, cold temperature dry-block on the market. It’s ideal for applications that demand strict quality control and regulatory process compliance. These applications include on-location validation and calibration of RTDs, thermocouples, thermometers, and sensors used with process control equipment such as medical freezers, laboratory refrigerators, cold rooms, blood banks, sterilizers (autoclaves), and freeze dryers.

Wide temperature range
–95 °C to 140 °C

Excellent accuracy
Accuracy using built-in referencethermometer readout: ±0.05 °C full range
Display accuracy: ±0.2 °C full range
Best-in-class stability
±0.015 °C full range

Fast cooling time
23 °C to –90 °C: 80 minutes
23 °C to –95 °C: 90 minutes
140 °C to 23 °C: 60 minutes

Portability
Weighs only 16 kg (35 lbs)
Built-in front and back handlesfor easy two-handed carry
Best measurement practices
Conforms with EURAMET cg-13 guidance on measurement practices for temperature calibrators

Manual Ranging.



Safety Design.



Data Hold.

Key features
• Lightweight, portable, and fast
• Built-in two-channel readout for PRT, RTD, thermocouple, 4-20 mA current
• True reference thermometry with accuracy to ±0.01 °C
• On-board automation and documentation
• Metrology performance in accuracy, stability, uniformity, and loading
